Home Socket dc power jack connector

dc power jack connector

Gangyuan T105 High quality  Universal 2 Pin 55mm dc power jack connector

  • Brand:

    Gangyuan
  • Item NO.:

    DB-8-5P9
  • Order(MOQ):

    10pcs
  • Payment:

    100% T/T Before Production
  • Product Origin:

    Zhejiang, China (Mainland)
  • Color:

    black
  • Shipping Port:

    Ningbo/Shenzhen
  • Lead Time:

    3 working days for payment
  • Product Detail

Gangyuan T105 High quality  Universal 2 Pin 55mm dc power jack connector

Basic Information

Item No: DB-8-5P9
Rating 2.5A 250V AC,5A 250VAC
Operation force 1.36kgf~6.8kgf
Terminal strength ≥80N
operating life ≥5000 cycles
Insulation resistance ≥100MΩ 500VDC

Dimension

 55 x 21 mm dc power jack socket female.jpg

Tact Switch Using Attention

1.Please consult us when considering to wash tact switches

2.Please don’t immerse soldering flux into tact s

3Please don’t paint soldering flux on the surface of switch terminals and other parts in PCB board

4.The second welding should be done after switches return to normal temperature



Our advantage

1. Excellent R&D team, clients design requests are welcome.

2. Experience of more then two decades in switch manufacturing.
3. Two thousands invention patents and 47 utility model patents.
4. Assembly process in 100,000 grade dust-free workshop.
5. Owing TS16949,ISO9001,ISO14001,OHSA18001 system.



Application

Tactile switch use for: Mini type portable equipment, PCB board, Digital products, Kitchen appliances, Communication products, white home appliance, black home appliance, small home appliance, Security products, Toys, Computers, body building apparatus, medical appliance;

act Tactile Switch
