Home Switch Tactile switch 05 Series tact switch dustproof tact switch 12V

dustproof tact switch 12V

5*5mm 4pin silent tact switch dustproof tact switch 12V

  • Brand:

    Gangyuan
  • Item NO.:

    KAN0543A
  • Order(MOQ):

    50 pcs
  • Payment:

    T/T
  • Product Origin:

    zhejiang/shenzhen
  • Color:

    yellow
  • Shipping Port:

    ningbo or shenzhen
  • Lead Time:

    3 Working Days after payment
  • Product Detail

5*5mm 4pin silent tact switch dustproof tact switch 12V

Basic Information

Item NO.
KAN0543A
Operating force
100gf/160gf/260gf±50gf
Rating
12V DC 50mA
Life cycles
40,000/50,000/60,000 cycles
Sulfuration resistance
40±2℃, 72h
Heat resistance
80±2℃, 96h

Dimension

tact switch smd push button 4 pines.jpg

Tact Switch Using Attention

1.Please consult us when considering to wash tact switches

2.Please don’t immerse soldering flux into tact switches

3Please don’t paint soldering flux on the surface of switch terminals and other parts in PCB board

4.The second welding should be done after switches return to normal temperature



Our advantage

1. Excellent R&D team, clients design requests are welcome.

2. Experience of more then two decades in switch manufacturing.
3. Two thousands invention patents and 47 utility model patents.
4. Assembly process in 100,000 grade dust-free workshop.
5. Owing TS16949,ISO9001,ISO14001,OHSA18001 system.



Application

Tactile switch use for: Mini type portable equipment, PCB board, Digital products, Kitchen appliances, Communication products, white home appliance, black home appliance, small home appliance, Security products, Toys, Computers, body building apparatus, medical appliance;
