Home Relay & Sensor 12V power low voltage relay

12V power low voltage relay

Suger cube Miniature size 12V power low voltage relay

  • Brand:

    HKE
  • Item NO.:

    HRS1KH3
  • Order(MOQ):

    10pcs
  • Payment:

    100% T/T Before Production
  • Product Origin:

    Zhejiang, China (Mainland)
  • Color:

    yellow
  • Shipping Port:

    Ningbo/Shenzhen
  • Lead Time:

    3 working days for payment
  • Product Detail


Suger cube Miniature size 12V power low voltage relay



Basic Information

Contact Form

1 Form A

Contact Material

Ag Alloy

Contact Rating

3A 220VAC/30VDC

Contact Resistance

Max. 50mΩ (6VDC 1A)





Load

Max. Switching Voltage

220VAC/30VDC

Max. Switching Current

3A

Max. Switching Power

660VA, 90W

Min. Switching Load

5VDC, 100mA



Life

Electrical

100,000 operations

Mechanical

10,000,000 operations


Dimension

relay 220v.jpg

Tact Switch Using Attention

1.Please consult us when considering to wash tact switches

2.Please don’t immerse soldering flux into tact switches

3Please don’t paint soldering flux on the surface of switch terminals and other parts in PCB board

4.The second welding should be done after switches return to normal temperature



Our advantage

1. Excellent R&D team, clients design requests are welcome.

2. Experience of more then two decades in switch manufacturing.
3. Two thousands invention patents and 47 utility model patents.
4. Assembly process in 100,000 grade dust-free workshop.
5. Owing TS16949,ISO9001,ISO14001,OHSA18001 system.



Application

Tactile switch use for: Mini type portable equipment, PCB board, Digital products, Kitchen appliances, Communication products, white home appliance, black home appliance, small home appliance, Security products, Toys, Computers, body building apparatus, medical appliance;

act Tactile Switch
