Home Switch Push button switch Latching lock Switch self-locking push button switch

Latching lock Switch self-locking push button switch

Silver Coated Terminal Black Flat Latching lock Switch self-locking push button switch

  • Brand:

    Gangyuan
  • Item NO.:

    PB22E09
  • Order(MOQ):

    1000pcs
  • Payment:

    100% T/T Before Production
  • Product Origin:

    Zhejiang, China (Mainland)
  • Color:

    blue and white
  • Shipping Port:

    Ningbo/Shenzhen
  • Lead Time:

    7 Working Days after payment
  • Product Detail


Silver Coated Terminal Black Flat Latching lock Switch self-locking push button switch


6 Pin surface mount push button switch is manufactured from a factory in China. Operating temperature is between -25℃ and 80℃, Housing dimension is 8.5*8.5mm, silver coated terminal type.


Basic Information

Product name push button switch
Operating temperature -25℃~80℃
Operating Relative Humidity ≤80℃
Dielectric withstanding Voltage 100mΩ/ DC250V<1min
Voltage Rating DC  30V
Current Rating 0.1A
Operation force 230+-70gf
Travel 2.5±0.2mm
Contact resistance 100mΩ


Dimension

PB21E09 .jpg


Tact Switch Using Attention

1.Please consult us when considering to wash tact switches

2.Please don’t immerse soldering flux into tact switches

3Please don’t paint soldering flux on the surface of switch terminals and other parts in PCB board

4.The second welding should be done after switches return to normal temperature



Our advantage

1. Excellent R&D team, clients design requests are welcome.

2. Experience of more then two decades in switch manufacturing.
3. Two thousands invention patents and 47 utility model patents.
4. Assembly process in 100,000 grade dust-free workshop.
5. Owing TS16949,ISO9001,ISO14001,OHSA18001 system.



Application

Tactile switch use for: Mini type portable equipment, PCB board, Digital products, Kitchen appliances, Communication products, white home appliance, black home appliance, small home appliance, Security products, Toys, Computers, body building apparatus, medical appliance;
