Home Relay & Sensor auto air conditioner relay

auto air conditioner relay

4 pin bistable relay module for auto air conditioner 25A 14VDC

  • Brand:

    HKE
  • Item NO.:

    CMA59
  • Order(MOQ):

    10pcs
  • Payment:

    100% T/T Before Production
  • Product Origin:

    Zhejiang, China (Mainland)
  • Color:

    yellow
  • Shipping Port:

    Ningbo/Shenzhen
  • Lead Time:

    14 working days for payment
  • Product Detail

4 pin bistable relay module for auto air conditioner 25A 14VDC

Basic Information

Product name automotive relay
Dimentions 20.4x15.1x22.0mm
Contact Material Ag Alloy
Contact Rating Motor:20A/10A 14VDC
Contact Resistance Max. 100mΩ (6VDC 1A)
Insulation Resistance Min.100MΩ 500VDC
Operating Temperature -40℃ to +125℃
Operation life 1,000,000ops(300ops/min)
Dielectric Strength 550VAC,50/60Hz,1 min
Nominal Coil Power 0.64W

Dimension

under voltage relay.jpg

Tact Switch Using Attention

1.Please consult us when considering to wash tact switches

2.Please don’t immerse soldering flux into tact s

3Please don’t paint soldering flux on the surface of switch terminals and other parts in PCB board

4.The second welding should be done after switches return to normal temperature



Our advantage

1. Excellent R&D team, clients design requests are welcome.

2. Experience of more then two decades in switch manufacturing.
3. Two thousands invention patents and 47 utility model patents.
4. Assembly process in 100,000 grade dust-free workshop.
5. Owing TS16949,ISO9001,ISO14001,OHSA18001 system.



Application

Tactile switch use for: Mini type portable equipment, PCB board, Digital products, Kitchen appliances, Communication products, white home appliance, black home appliance, small home appliance, Security products, Toys, Computers, body building apparatus, medical appliance;

act Tactile Switch
Leave A Message

If you want to purchase switch products and need to know quotations, parameters or solutions, please leave us a message, and we will give you a satisfactory reply within 2 hours.

  • #
  • #
  • #
  • #
  • If you have questions or suggestions,please leave us a message,we will reply you as soon as we can!
