Home Switch Micro switch G20 Series 16a spst micro switch

16a spst micro switch

micro switch 16a 125/250v SPST 40t85 5e4 micro switch

  • Brand:

    Gangyuan
  • Item NO.:

    G20-16EN-150-12
  • Order(MOQ):

    10pcs
  • Payment:

    100% T/T Before Production
  • Product Origin:

    Zhejiang, China (Mainland)
  • Color:

    black
  • Shipping Port:

    Ningbo/Shenzhen
  • Lead Time:

    14 working days for payment
  • Product Detail

micro switch 16a 125/250v SPST 40t85 5e4 micro switch


Basic Information


Product Name Micro Switch
Operation Force 150±50gf
Insulation resistance ≥100MΩ
Contact resistance 200mΩ
Rating 16A 125V/250VAC
Life expectancy 10000 cycles
Operating temperature -25℃+125
Dielectric Withstanding Voltage AC 1500V 1Minute
Protection Level


High Level


Dimension



 Product Features

1. Type: G20 Micro switch

2. Circuit Code: SPST-NO

3. Lever Type: No lever

4. Electrical Rating: 16(10) 125/250vac,5e4.25t125


 Our advantage


1. The factory has more than 20 years of experience in the field of switch manufacturing.

2. Variety of categories. More than 2000 models.

3. Good quality. Using raw materials imported from Japan and South Korea.

    More than 85% of product automated manufacturing coverage.

4. Excellent R&D team, clients design requests are welcome.

5. Two thousands invention patents and 47 utility model patents.

6. Assembly process in 100,000 grade dust-free workshop.
7. Owing TS16949,ISO9001,ISO14001,OHSA18001 system.

8. After-sales service team. Global radiation multiple service outlets.



 Application


Micro switch use for: Mini type portable equipment, PCB board, Digital products, Kitchen appliances, Communication products, white home appliance, black home appliance, small home appliance, Security products, Toys, Computers, body building apparatus, medical appliance;


  FAQ


1. Q: Are you manufacture/ factory? Location?

    A: Yes, three palnts located in Shenzhen , Zhejiang, Hubei province.

2. Q: Can I get free sample before placing an order ? MOQ?

    A: Yes, free samples will get ready within 3~5 days. MOQ1,000pcs.

3. Q: What about the delivery time?
    A: Stable delivery. 7-15 working days.

4. Q: What about terms of payment ?

    A: T/T, L/C, Paypal, Cash etc.

5. Q: Can you customize products according to the design drawing?
    A: We have independent R&D center in Shezhen, ODM/OME project is welcome.

6.Q: Do you test all your goods before delivery?

   A: Yes, we have 100% test before delivery.
