Home Switch Rocker switch 3A 2pin automotive Rocker Switch wiring

3A 2pin automotive Rocker Switch wiring

Hot Sell Wiring a rocker switch diagram 3A 2pin automotive Rocker Switch.

  • Brand:

    Gangyuan
  • Item NO.:

    KCD601H2
  • Order(MOQ):

    1000
  • Payment:

    T/T before shipment
  • Product Origin:

    China
  • Color:

    black or grey
  • Shipping Port:

    Ningbo/Shenzhen
  • Lead Time:

    5-7 Working Days after payment
  • Product Detail

Wiring 3A 2pin automotive Rocker Switch use for all electronic products.


Product Description


Model Name:

automotive Rocker Switch

Model No.:

KCD601H2

Dimension:

13.2X14.5

Rating:

3-40A, 3-220V

Contact Resistance:

35mΩ max

Insulation Resistance:

500VDC 100MΩ min

Dielectric Strength:

1500VAC,1Minute

Operating Temperature:

-25℃~+85℃

Electrical Life:

>10000 Cycles

Certifications:

CE,CQC,ROHS,VDE



Dimension


Soldering



Quick connecting








Application

Rocker switches Widely applied to controlling all kinds of household appliances such as water dispenser, treadmill, coffee pot, drinking fountains, computer speakers, battery cars, motorcycles, ion TVs, coffee makers, plugs, massage machines, Lighting, small appliances and other products, ,printers, televisions, computer speakers, battery cars, motorcycles, TVs, row plugs, electric fans , electric oil Ting, heater etc.

Leave A Message

If you want to purchase switch products and need to know quotations, parameters or solutions, please leave us a message, and we will give you a satisfactory reply within 2 hours.

Related Products
Red Light Rocker Switch
Round Rocker Switch with Led Light

RS601C1 round rocker Switch with LED or Neon light, terminal tail welding wire processing could be provided if required.

Rocker Switch
Narrow Shape Rocker Switch 21x9.7mm

This series come in narrowest shape with excellent electrical performance, printing on stem could be made as customers request.

Rocker Switch
6A ON OFF ON Rocker Switch

RS601B Series rocker switch, long or short terminal for options, printing could be made at cusotmer request.

Oval rocker switch
Led Light Oval Rocker Switch

Oval rocker switch, light colors with red, blue, green, yellow. Great components for home appliance, industry control, computers etc.

Double Hole Rocker Switch
DPDT Rocker Switch 21x24mm

This series rocker switches posses different rocker colors, such as red, black, white, green etc. Base colors could be black or white. simple operation for DIY.

Rocker Switch
3pin on and off carling marine rocker switches wired and lighted

Rocker switches on and off with lighted, 3pin wiring smd.

Mini Rocker Switch
Illuminated Red LED On Off 4 Pin Mini Rocker Switch

PS102: 21*15mm, 6A 125VAC/ 10A 250VAC, CE、CQC、ROHS、VDE approval rocker switch.

Rocker Switch
2 Position 2 Pins On Off Electric Square Rocker Switch

RS601A normal type: 2 Pins, 21*15mm, ON-OFF/ ON-ON/ ON-OFF-ON type mini rocker switch.
