6.2mm Waterproof Square Type Middle-travel SMD Tact Switch KAN6247
Item NO.:
KAN6247-0514M1Order(MOQ):
1000pcsPayment:
100% T/T Before ProductionProduct Origin:
Zhejiang, China (Mainland)Color:
silver and blueShipping Port:
Ningbo/ShenzhenLead Time：
7 Working Days after paymentWaterproof Square Type Middle-travel SMD Tact Switch
Product Description:
Specitications:
Contact resistance
≤100mΩ
Heat resistance
80±2℃, 96h
Insulation Resistance
≥100MΩ
Moisture resistance
96h
Dielectric voltage proof
250V AC(50Hz/60Hz)/1min
Sulfuration resistance
96h
Resistance to low temperature
-30±2℃, 96h
Salt Mist
12h±1h
If you want to purchase switch products and need to know quotations, parameters or solutions, please leave us a message, and we will give you a satisfactory reply within 2 hours.
